Parcel Area Labels are exposed (ParcelAreaLabel class).

Stacked, split, and multiple profile views can now be created using ProfileView.Create().

You can now extract elements from surface objects (with ExtractBorder(), ExtractWatershed(), and ExtractGridded() methods).

You can now extract contour information from a surface with several new ExtractContours() and related methods.

You can now sample Surface Points along linear entities with the SampleElevations() method.

The AeccSurfaceOpAdd3DFaces Surface operation is now exposed.

You can now calculate the bounded volume of a surface with Surface.GetBoundedVolumes().

Import/Export Points: Imports points from a point file to an existing PointGroup and exports points from a specified PointGroup to a point file.

The collection of all point description key sets in a drawing is accessed with the static PointDescriptionKeySetCollection.GetPointDescriptionKeySets() method.

Description Keys: Description keys are exposed with the PointDescriptionKey class.

The collection of all user-defined properties defined in a drawing is accessed via the CivilDocument.PointUDPs property. You can create/modify user-defined properties, and they can be set on CogoPoint objects.

User Defined Properties: User-defined properties are exposed.

Point Group Queries: Standard and custom point group queries are exposed: StandardPointGroupQuery and CustomPointGroupQuery classes.

CogoPoint.PrimaryPointGroupId indicates the point group a CogoPoint belongs to. CivilDocument.PointGroups is the collection of all point groups in the drawing.

You can access/modify all point group properties.

Point Groups (PointGroup class): Point Groups are now exposed.

You can access/modify all COGO point properties, including styles and labels.

COGO Point object (CogoPoint class): Coordinate Geometry (COGO) points are now exposed.

In AutoCAD Civil 3D 2013, these classes and types will be in the "". As an example, previous releases will expose "Land" related classes and types in the "" namespace.

#Autodesk civil 3d 2013 update update

The "feature" part of the namespace has been removed, so you will have to update your "using" statements to include the new namespace. NET API: In AutoCAD Civil 3D 2013, we introduced a namespace restructuring that will simplify referencing objects moving forward. The objects and interfaces exposed have remained the same, but you should reference the new libraries, which are installed by default to: "C:\Program Files\Common Files\Autodesk Shared\Civil Engineering 100". What's New in the AutoCAD Civil 3D 2013 APIĬOM API: If you are using the AutoCAD Civil 3D 2013 COM API, you need to update the object version to 10.0 (from 9.0 used in AutoCAD Civil 3D 2012). To complete the migration, right-click the item and select the migration command. An item that requires migration displays the "out-of-date" icon to provide a visual cue that it requires migration. On the Prospector tab in Toolspace, expand the Projects collection. The migrated project files are not backwards-compatible with previous versions of AutoCAD Civil 3D. When you perform the migration, Vault checks the project out, migrates the files, then checks them back in, and the version number is incremented. Vault projects must also be migrated due to the requirement to support a 64-bit operating system.

Support for 64-bit Operating System requires Vault project migration Other topics that help in increasing efficiency include styles, proper AutoCAD drafting techniques, the methodology needed to create linework effectively for variables used in defining symbology, surfaces, categorizing points, and importing imagery.Support for 64-bit Operating System requires database migrationĭue to the requirement to support a 64-bit operating system, existing external project point databases and survey database files must be migrated to Microsoft® SQL Server® Compact 3.5 format from Microsoft Access Database format.

Data collection, least square analysis, and traverses are also covered.

#Autodesk civil 3d 2013 update how to

Your students will learn how to import the converted field equipment survey data into a standardized environment in Civil 3D and to use the automation tools to create an Existing Condition Plan. This book will equip your students with the basic knowledge needed to use Civil 3D efficiently in a typical daily work flow for a surveyor. AutoCAD Civil 3D 2013 for Surveyors is an in-depth textbook intended for students, surveyors and survey technicians that do not necessarily need all of the functionality that is taught in other AutoCAD Civil 3D textbooks.
